ARESA 4000 - 3500 FCAT HSC

HIGH SPEED CATAMARAN FERRY


This catamaran type vessel is specially designed for transporting passengers at high speed with the greatest comfort and space available. The ARESA 4000 - 3500 FCAT HSC is specially designed to develop high speeds in adverse sea conditions, providing maximum comfort to its passengers.

Its interiors are designed to carry the maximum passenger capacity in different zones and classes, including different areas of rest or use according to the needs of the end customer.

Initially designed to be propelled with Diesel inboard engines and waterjets to reach high speeds, it can also be equipped with standard propulsion, with propellers, in case of requiring speeds below 35 knots. Built entirely in naval Aluminium to obtain a reduced weight throughout its structure, it can also be built in GRP composite materials for greater comfort during navigation.


Request more info
I have read and accept the privacy policy and the legal notice
HIGH SPEED CATAMARAN FERRY photo 1
HIGH SPEED CATAMARAN FERRY photo 2
HIGH SPEED CATAMARAN FERRY photo 3
HIGH SPEED CATAMARAN FERRY photo 4
HIGH SPEED CATAMARAN FERRY photo 5
HIGH SPEED CATAMARAN FERRY photo 6

Features

Principal particulars icon
Principal particulars
Length overall
40.00 - 35.00 m
Beam
11.00 - 9.50 m
Draught
1.50 m
Depth
3.10 m
Generators
400 Kva
Deadweight icon
Deadweight
Crew
16 p
Passengers
219 p
Seats
163
Vip seats
56
Fuel
30.000 l
Fresh water
1.500 l
Black grey water
1.200 l
Load
5.100 kg
Performance icon
Performance
Max speed
40 kn
Cruise speed
35 kn
Economic speed
25 kn
Range
500 NM
Propulsion icon
Propulsion
Main engines
9.800 HP
Propulsion
Waterjet
Construction material icon
Construction material
Material
GRP
Equipment icon
Equipment
Bar
Galley
W.C
Cargo Hold
Luggage Compartment
Captain Cabin
Bathing Platform
Forward Footbridge
Open Upper Deck
High Speed
Rescue Boat
CO2 Installation
TV/Audio Speakers System
HIGH SPEED CATAMARAN FERRY video
